Fujitsu PRIMERGY RX2530 M6 User Manual

▶
"Connecting the power cord" on page 62.
▶
"Switching on the server" on page
66.
▶
If applicable, "Installing the front cover with lock" on page 66.
16.5.3 Removing the iRMC microSD card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
"Shutting down the server" on page
48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
▶
Remove the riser module 2, see "Removing a riser module" on page 69.
Removing the iRMC microSD card
Figure 263: Removing the iRMC microSD card
System board and components
362 Upgrade and Maintenance Manual RX2530 M6

Fujitsu PRIMERGY RX2530 M6 Specifications

General

Form Factor	2U Rack
Chipset	Intel C621A
Processor	Intel Xeon Scalable Processors (3rd Gen)
Memory Type	DDR4
Memory Slots	16
Storage	2.5-inch or 3.5-inch SAS/SATA/NVMe drives
Drive Bays	12 x 2.5" or 3.5"
Network Controller	Intel Ethernet Controller (optional)
Expansion Slots	Up to 3 x PCIe Gen4 slots
Power Supply	Redundant hot-plug power supplies, various wattage options available
Management	Fujitsu ServerView Suite
Operating System Support	Windows Server, Linux, VMware
RAID Controller	Optional RAID controllers (LSI MegaRAID)
