Figure 172: Example rear side with installed full height riser module
▶
Install the full height riser module in the chassis.
Concluding steps
▶
"Reassembling" on page
57.
▶
"Disconnecting the power cord" on page
49.
▶
"Switching on the server" on page 66.
▶
If applicable, "Installing the front cover with lock" on page 66.
9.7 Flash backup unit (FBU)
9.7.1 Positions of the FBUs
You can install up to two FBUs.
Expansion cards and backup units
RX2530 M6 Upgrade and Maintenance Manual 251
