14 Front panel
14.1 Safety notes
CAUTION
▶
When inserting the COP (Common Operation Panel) into the
server, ensure not to pinch or strain any connected cables.
▶
Circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Always discharge static
build-up (e.g. by touching a grounded object) before handling
electrostatic-sensitive devices (ESDs).
▶
Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
▶
For more information, see "Important information" on page 31.
14.2
Basic information
In case of a defective ambient temperature sensor, please replace Common
Operation panel (COP).
COP
The COP is mounted on the right side ear. A flat cable is used for connection to
the system board.
Front VGA (option)
A front VGA connector can be installed at the front panel of some
configurations.
