Position Logical drive
number
ServerView RAID Manager display
name
[29] 29 Vendor Product (29)
[30] 30 Vendor Product (30)
[31] 31 Vendor Product (31)
7.6.2 Installing EDSFF SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
The EDSFF SSD module is controlled by an onboard controller. For
more information, see the "Intel Virtual RAID on CPU (Intel VROC) User
Guide".
The VMD function has to be enabled in the BIOS.
If the VMD function is disabled in the BIOS, the EDSFF SSD module is
not supported.
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
Locate the correct drive bay, see "Overview of configurations" on page 174.
▶
Depending on your configuration and OS: "Shutting down the server" on
page 48.
Hard disk drive (HDD) / solid state disk (SSD)
176 Upgrade and Maintenance Manual RX2530 M6
