Riser module Slot
offered
Type Description
Riser module 1 Slot 1 PCIe Gen4 x16 Low-profile slot
Riser module 2 Slot 2 PCIe Gen4 x16 Low-profile slot
Riser module 3 Slot 3 PCIe Gen4 x16
(CPU2)
Low-profile slot (Liquid
Cooling, option)
Internal RAID
riser module
Riser
slot
PCIe Gen4 x8 Low-profile slot
As an option, a full height riser module can be installed. In this case the
slot 2 is not available and slot 3 can be equipped with a full height
expansion card.
As an option, a rear HDD/SSD cage can be installed. In this case riser
module 2 and riser module 3 are not available.
As an option, an Internal RAID riser module can be installed behind
HDD backplane.
As an option, an LC kit can be installed. In this case riser module 3 is
occupied by the tubes outlets.
9.3 Handling slot brackets
9.3.1 Installing slot brackets
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Use the low profile bracket perforated for relevant controllers. No
bracket needed for installing the internal RAID controller in the internal
RAID riser module.
Expansion cards and backup units
198 Upgrade and Maintenance Manual RX2530 M6
