4.6 Reassembling
4.6.1 Safety notes
CAUTION
▶
Before attaching the covers, make sure no unnecessary parts or
tools are left inside the server.
▶
The top cover must be replaced as soon as possible for purposes
of cooling, to comply with EMC regulations (regulations regarding
electromagnetic compatibility) and to prevent fires.
▶
For more information, see "Important information" on page 31.
4.6.2
Installing the top covers
Installing the cover 2
Figure 11: Installing the cover 2
▶
Place the cover 2 in such way that the bolts inside the cant of the cover fit in
the corresponding recesses in the chassis (1).
CAUTION
▶
Take care that all cables are inside the chassis.
▶
Push the cover 2 to the front side using the green touch points (2).
Basic hardware procedures
RX2530 M6 Upgrade and Maintenance Manual 57
