Insert the riser card.
▶
Fasten the riser card with three screws (see circles).
▶
Install the expansion card, see "Installing the expansion card" on page
221.
Concluding steps
▶
Install the corresponding riser module, see "Handling riser modules" on
page 68
.
▶
"Reassembling" on page 57.
▶
"Connecting the power cord" on page 62.
▶
"Switching on the server" on page 66.
▶
If applicable, "Installing the front cover with lock" on page 66.
9.6.6 Installing the internal RAID controller
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
–
Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 75.
▶
If applicable, "Removing the front cover with lock" on page
48.
▶
"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
▶
Please read the documentation supplied with the expansion card.
Expansion cards and backup units
234 Upgrade and Maintenance Manual RX2530 M6
