Figure 249: Installing the riser module
▶
Install the corresponding riser module, see "Installing a riser module" on
page 69.
Concluding steps
▶
"Reassembling" on page
57.
▶
"Connecting the power cord" on page 62.
▶
"Switching on the server" on page 66.
▶
If applicable, "Installing the front cover with lock" on page 66.
▶
"Resuming BitLocker functionality" on page 93.
15.3 Removing the serial interface
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Serial interface
340 Upgrade and Maintenance Manual RX2530 M6
