Preliminary steps
▶
"Suspending BitLocker functionality" on page 75.
▶
If applicable, "Removing the front cover with lock" on page
48.
▶
"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
Removing the serial interface
Figure 250: Disconnecting the serial interface cable
▶
Disconnect the serial interface cable from the system board connector
"SERIAL".
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 69.
Serial interface
RX2530 M6 Upgrade and Maintenance Manual 341
