Installing the new EDSFF SSD module
▶
If applicable, install the EDSFF SSD in the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 120.
▶
Install the EDSFF SSD module, see "Installing an EDSFF SSD module" on
page
178.
Concluding steps
▶
If applicable, "Switching on the server" on page 66.
▶
If applicable, rescan available devices from your OS.
▶
If applicable, "Installing the front cover with lock" on page 66.
7.6.5 Replacing a 16x EDSFF SSD backplane
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
There are two 16x EDSFF SSD backplanes. The second SSD backplane can
be replaced in the same way.
Preliminary steps
▶
"Locating the defective server" on page 45
.
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 183
