Tools: – Installation frame included: tool-less
– Installation frame excluded: Phillips PH1 / (+) No. 1 screw driver
The EDSFF SSD module is controlled by an onboard controller. For
more information, see the "Intel Virtual RAID on CPU (Intel VROC) User
Guide".
The VMD function has to be enabled in the BIOS.
If the VMD function is disabled in the BIOS, the EDSFF SSD module is
not supported.
CAUTION
All HDD/SSD modules (drives) must be uniquely identified so that they
can be reinstalled in their original bays later. If this is not done, existing
data can be lost.
Preliminary steps
▶
"Locating the defective server" on page 45.
▶
If applicable, "Removing the front cover with lock" on page 48
.
▶
Identify the physical location of the EDSFF SSD module, see "Overview of
configurations" on page 174.
▶
Prepare the removing of the EDSFF SSD module.
▶
Depending on your configuration and OS: "Shutting down the server" on
page 48.
Removing the defective EDSFF SSD module
▶
Remove the EDSFF SSD module, see "Removing an EDSFF SSD module"
on page 180.
▶
If applicable, remove the EDSFF SSD from the installation frame, see
"Handling HDDs or SSDs without installation frame" on page 120.
Hard disk drive (HDD) / solid state disk (SSD)
182 Upgrade and Maintenance Manual RX2530 M6

Fujitsu PRIMERGY RX2530 M6 Specifications

General

Form Factor	2U Rack
Chipset	Intel C621A
Processor	Intel Xeon Scalable Processors (3rd Gen)
Memory Type	DDR4
Memory Slots	16
Storage	2.5-inch or 3.5-inch SAS/SATA/NVMe drives
Drive Bays	12 x 2.5" or 3.5"
Network Controller	Intel Ethernet Controller (optional)
Expansion Slots	Up to 3 x PCIe Gen4 slots
Power Supply	Redundant hot-plug power supplies, various wattage options available
Management	Fujitsu ServerView Suite
Operating System Support	Windows Server, Linux, VMware
RAID Controller	Optional RAID controllers (LSI MegaRAID)
