The EDSFF SSD module is controlled by an onboard controller. For
more information, see the "Intel Virtual RAID on CPU (Intel VROC) User
Guide".
The VMD function has to be enabled in the BIOS.
If the VMD function is disabled in the BIOS, the EDSFF SSD module is
not supported.
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
Identify the physical location of the EDSFF SSD module, see "Overview of
configurations" on page
174.
▶
Prepare the removing of the EDSFF SSD module.
▶
Depending on your configuration and OS: "Shutting down the server" on
page 48.
Removing an EDSFF SSD module
Figure 101: Opening the locking lever
Hard disk drive (HDD) / solid state disk (SSD)
180 Upgrade and Maintenance Manual RX2530 M6
