Installing an EDSFF SSD module

Figure 99: Opening the locking lever

▶

Pinch the green locking clips (1) and open the locking lever (2).

Hard disk drive (HDD) / solid state disk (SSD)

178 Upgrade and Maintenance Manual RX2530 M6
