Pull the dummy cover out of the bay.
CAUTION
▶
Keep the dummy cover for future use.
▶
If you remove the accessible drive again and do not replace it with
a new one, the dummy cover must be reinstalled to comply with
EMC regulations and to satisfy cooling requirements and fire
protection measures.
Installing the ODD
▶
If no ODD has been installed before:
▶
Remove the two screws and take the ODD latch from the chassis (see
Figure 225).
Figure 227: Installing the ODD latch on the ODD
▶
Fasten the ODD latch with two screws to the rear side of the ODD (see
circles).
Accessible drives
RX2530 M6 Upgrade and Maintenance Manual 317

Fujitsu PRIMERGY RX2530 M6 Specifications

General

Form Factor	2U Rack
Chipset	Intel C621A
Processor	Intel Xeon Scalable Processors (3rd Gen)
Memory Type	DDR4
Memory Slots	16
Storage	2.5-inch or 3.5-inch SAS/SATA/NVMe drives
Drive Bays	12 x 2.5" or 3.5"
Network Controller	Intel Ethernet Controller (optional)
Expansion Slots	Up to 3 x PCIe Gen4 slots
Power Supply	Redundant hot-plug power supplies, various wattage options available
Management	Fujitsu ServerView Suite
Operating System Support	Windows Server, Linux, VMware
RAID Controller	Optional RAID controllers (LSI MegaRAID)
