Installing a 3.5-inch HDD in a 3.5-inch installation frame
Figure 38: Installing the 3.5-inch HDD in the 3.5-inch installation frame (A)
▶
Lay the 3.5-inch HDD into the 3.5-inch installation frame as shown.
Figure 39: Installing the 3.5-inch HDD in the 3.5-inch installation frame (B)
▶
Fasten the 3.5-inch HDD with four screws.
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 121
