CAUTION
▶
Keep the dummy module for future use.
▶
Always replace dummy modules into unused HDD/SSD bays to
comply with applicable EMC regulations and satisfy cooling
requirements.
Installing a 2.5-inch HDD/SSD module
Figure 60: Opening the locking lever
▶
Pinch the green locking clips (1) and open the locking lever (2).
Figure 61: Installing the 2.5-inch HDD/SSD module
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 141
