After installing or removing an additional backplane, never forget to
change the system information using the Chassis ID Prom Tool.
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
"Shutting down the server" on page
48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
▶
Remove the riser modules 2 and 3, see "Removing a riser module" on
page 69.
Figure 87: Installing the rear HDD/SSD cage (A)
▶
Insert the rear HDD/SSD cage. The two guide pins (A) must fit in the holes.
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 167
