Figure 110: Fan bays occupied with fan cage foams
Numbering of the fan modules
Figure 111: Numbering of the fan modules
Pos. CPU Fans
1 CPU 1 FAN 1 (A/B)
2 CPU 1 FAN 2 (A/B)
3 CPU 1 FAN 3 (A/B)
4 CPU 1 FAN 4 (A/B)
5 CPU 2 FAN 5 (A/B)
Fans
