Fujitsu PRIMERGY RX2530 M6

The proceeding for installing/removing is identic for the 2.5-inch or 3.5-
inch HDD configuration.
Figure 221: Position of the ODD bay - example 3.5-inch HDD configuration
Figure 222: Position of the ODD bay - example 2.5-inch HDD configuration
Figure 223: Routing ODD cable - example 3.5-inch HDD configuration
1 ODD cable
Accessible drives
314 Upgrade and Maintenance Manual RX2530 M6
