Push in the lock on the left side (1) and attach the front cover in a slight
angle to the front (2). Ensure that the noses (A, B) fit in the corresponding
recesses.
▶
Press the front cover in place until the lock clicks in.
Figure 19: Installing the front cover with lock (B)
▶
Insert the key
.
▶
Turn the key in locked position.
Basic hardware procedures
RX2530 M6 Upgrade and Maintenance Manual 67
