7.4.1.3 Configuration with up to 24 HDD/SSD or PCIe SSD modules
Figure 57: Configuration with up to 24 HDD/SSD or PCIe SSD modules
Position HDD install order ServerView RAID Manager
display name
[0] HDD0 / PCIe SSD0 Vendor Product (0)
[1] HDD1 / PCIe SSD1 Vendor Product (1)
[2] HDD2 / PCIe SSD2 Vendor Product (2)
[3] HDD3 / PCIe SSD3 Vendor Product (3)
[4] HDD4 / PCIe SSD4 Vendor Product (4)
[5] HDD5 / PCIe SSD5 Vendor Product (5)
[6] HDD6 / PCIe SSD6 Vendor Product (6)
[7] HDD7 / PCIe SSD7 Vendor Product (7)
[8] HDD8 / PCIe SSD8 Vendor Product (8)
[9] HDD9 / PCIe SSD9 Vendor Product (9)
[10] HDD10 / PCIe SSD10 Vendor Product (10)
[11] HDD11 / PCIe SSD11 Vendor Product (11)
[12] HDD12 / PCIe SSD12 Vendor Product (12)
[13] HDD13 / PCIe SSD13 Vendor Product (13)
[14] HDD14 / PCIe SSD14 Vendor Product (14)
[15] HDD15 / PCIe SSD15 Vendor Product (15)
[16] HDD16 / PCIe SSD16 Vendor Product (16)
Hard disk drive (HDD) / solid state disk (SSD)
RX4770 M6 Upgrade and Maintenance Manual 141
