14.3 Common operation panel (COP)
14.3.1 Replacing the COP
Field Replaceable Unit
(FRU)
Hardware: 35 minutes
Software: 5 minutes
Tools:
– Phillips PH1 / (+) No. 1 screw driver
– Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Note on system information backup/restore
The COP contains the Chassis ID EPROM that contains system information
like server name and model, housing type, serial number and manufacturing
data. To avoid the loss of non-default settings when replacing the system
board, a backup copy of important system configuration data is automatically
stored from the system board NVRAM to the Chassis ID EPROM.
CAUTION
For that reason the COP and the system board must not be replaced
simultaneously! In this case, restoring the system configuration data on
the system board would fail.
▶
Reconfigure the BIOS/iRMC and restore the system information like
server name, server model, housing type, serial number and
manufacturing data manually by Chassis ID Prom Tool.
In case replacing the front panel and system board at the same time, the
system information like server name and model, housing type, serial number
and manufacturing data are not restored automatically. So never forget to
restore it manually by Chassis ID Prom T
ool.
Preliminary steps
▶
"Locating the defective server" on page 97.
▶
"Suspending BitLocker functionality" on page 81.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
Front panel
316 Upgrade and Maintenance Manual RX4770 M6
