Fujitsu PRIMERGY RX4770 M6 - 16 Appendix A; 16.1 Mechanical overview

16 Appendix A
16.1 Mechanical overview
16.1.1
Server front
16.1.1.1 2.5-inch HDD/SSD configuration
Figure 234: Server front with 8x 2.5-inch HDDs/SSDs or 8x 2.5-inch PCIe SSDs
1 ID card
2 ODD
3
Front VGA
4 Common operation panel
5 2.5-inch HDD/SSDs/PCIe SSDs (8x)
The ODD (2) is an option.
