14 Front panel
14.1 Safety notes
CAUTION
â–¶
When inserting the COP (Common Operation Panel) into the
server, ensure not to pinch or strain any connected cables.
â–¶
Circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Always discharge static
build-up (e.g. by touching a grounded object) before handling
electrostatic-sensitive devices (ESDs).
â–¶
Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
â–¶
For more information, see "Important information" on page 29
.
14.2 Basic information
In case of a defective ambient temperature sensor, please replace Common
Operation panel (COP).
COP
The COP is mounted on the right side ear
. A flat cable is used for connection to
the system board.
Front VGA
A front VGA connector is installed at the front of the server.
RX4770 M6 Upgrade and Maintenance Manual 315
