7.4.8 Replacing the SAS expander board

Field Replaceable Unit

(FRU)

Hardware: 20 minutes

Tools: Phillips PH2 / (+) No. 2 screw driver

Preliminary steps

▶

"Locating the defective server" on page 97

▶

If applicable,"Removing the front cover with lock" on page 45.

▶

"Shutting down the server" on page 46.

▶

"Disconnecting the power cord" on page 47.

▶

"Getting access to the component" on page 48.

▶

"Removing the fan cage" on page 64.

Removing the defective SAS expander board

▶

If applicable, remove the front VGA, see "Replacing the front VGA" on

page 323

▶

Disconnect all cables from the SAS expander board.

Hard disk drive (HDD) / solid state disk (SSD)

162 Upgrade and Maintenance Manual RX4770 M6
