Installing the OCP dummy cover
Figure 100: Installing the OCP dummy cover
▶
Place the OCP dummy cover with the guiding pin onto the OCP slot (1).
▶
Close the OCP dummy cover
.
▶
Fasten the knurled screw (2).
Concluding steps
▶
"Connecting the power cord" on page
59.
▶
"Switching on the server" on page 60.
9.5.4 Replacing the OCP module
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: tool-less
MAC addresses are stored on OCP module itself. When replacing OCP
module, MAC addresses are changed. Inform the customer about these
new MAC addresses. MAC addresses will not be changed by replacing
the system board.
Expansion cards and backup units
192 Upgrade and Maintenance Manual RX4770 M6
