13.3.5 Replacing the ODD
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver (for ODD latch)
–
Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
"Locating the defective server" on page
97
.
▶
"Removing backup and optical disk media" on page 84.
▶
"Suspending BitLocker functionality" on page 81.
▶
If applicable,"Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 48.
▶
"Removing the fan cage" on page 64.
Removing the defective ODD
▶
Remove the ODD, see "Removing the ODD" on page 308.
Installing the new ODD
▶
Install the ODD, see "Installing the ODD" on page 303.
Concluding steps
▶
"Installing the fan cage" on page 66.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord" on page 59.
▶
"Switching on the server" on page 60.
Accessible drives
312 Upgrade and Maintenance Manual RX4770 M6
