Fujitsu PRIMERGY RX4770 M6 - Replacing a GPU Card from a Riser Module

▶
Remove the GPU card from the riser module.
Figure 128: Installing the slot cover - example riser module left
▶
Install the slot clover.
Concluding steps
▶
Install the corresponding riser module, see "Installing a riser module" on
page 63
.
▶
"Reassembling" on page 53.
▶
"Connecting the power cord" on page 59.
▶
"Switching on the server" on page 60.
▶
If applicable,"Installing the front cover with lock" on page 61.
▶
"Resuming BitLocker functionality" on page 104.
9.8.3 Replacing a GPU card from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Expansion cards and backup units
RX4770 M6 Upgrade and Maintenance Manual 223
