Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 97
▶
"Suspending BitLocker functionality" on page
81.
▶
If applicable,"Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 48.
▶
"Locating the defective component" on page 44.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 63.
Removing the defective GPGPU card
▶
Remove the GPU card, see "Removing a GPU card" on page 222.
Installing the new GPGPU card
▶
Install the GPU card, see "Installing a GPU card (example NVDIA Tesla
V100S)" on page 215 or "Installing a GPU card (example
RTX4000/6000/8000)" on page 218.
Concluding steps
▶
Install the corresponding riser module, see "Installing a riser module" on
page 63.
▶
"Reassembling" on page 53
▶
"Connecting the power cord" on page 59
▶
"Switching on the server" on page 60
▶
If applicable,"Installing the front cover with lock" on page 61.
▶
"Enabling replaced components in the BIOS" on page 99
Expansion cards and backup units
224 Upgrade and Maintenance Manual RX4770 M6
