9.6 Expansion cards in standard PCIe slots
9.6.1 Installing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: Tools: Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 81
.
▶
If applicable,"Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 48.
▶
If applicable, "Removing a riser module" on page 63.
Installing the expansion card
Example SAS CP500i RAID controller in slot 3:
Expansion cards and backup units
