Fujitsu PRIMERGY RX4770 M6 - Removing the Irmc Microsd Card

▶
Install the riser modules, see "Installing a riser module" on page 63.
▶
"Reassembling" on page
53.
▶
"Connecting the power cord" on page 59.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
15.5.3 Removing the iRMC microSD card
Upgrade and Repair Unit
(URU)
Hardware: 30 minutes
Tools:
● Phillips PH2 / (+) No. 2 screw driver (for cover 2)
● a pair of side-cutting pliers
Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 45
.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 48.
▶
Remove the riser modules, see "Installing a riser module" on page 63.
▶
"Removing the fan cage" on page 64.
▶
"Removing the air duct 1 (top system board)" on page 68.
▶
"Removing the top system board carrier" on page 73.
▶
"Removing the OCP air duct" on page 70.
System board and components
RX4770 M6 Upgrade and Maintenance Manual 347
