Fujitsu PRIMERGY RX4770 M6 - Removing an Expansion Card from a Riser Module

▶
"Switching on the server" on page 60
.
▶
If applicable,"Removing the front cover with lock" on page 45.
▶
If applicable, "Updating expansion card firmware" on page 89.
▶
"Resuming BitLocker functionality" on page 104.
9.7.2 Removing an expansion card from a riser module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 81
.
▶
If applicable,"Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 48.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 63.
Removing an expansion card from a riser module
▶
If necessary, disconnect the cables from the expansion card.
Expansion cards and backup units
210 Upgrade and Maintenance Manual RX4770 M6
