Fujitsu PRIMERGY RX4770 M6 User Manual

13.3.2 ODD latch
Storing the ODD latch
Figure 185: Storing the ODD latch
The ODD latch is fastened with two screws on the bottom plate of the ODD
bay.
▶
Remove the two screws.
▶
Remove the ODD latch from its storing location.
13.3.3
Installing the ODD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver (for ODD latch)
– Phillips PH2 / (+) No. 2 screw driver (for cover 2)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 81
.
▶
If applicable,"Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
Accessible drives
302 Upgrade and Maintenance Manual RX4770 M6
