4.1
1.2
Installing the fan cage
Figure 25: Installing the fan cage
â–¶
Position the fan cage on the top system board.
Figure 26: Closing the locks
â–¶
Close the green locks (see circles).
Basic hardware procedures
66
Upgrade and Maintenance Manual
RX4770 M6
65
67
