If applicable, "Updating expansion card firmware" on page 89
.
â–¶
"Resuming BitLocker functionality" on page 104
9.9 Replacing a riser card
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
â–¶
"Locating the defective server" on page 97
.
â–¶
If applicable, "Removing the front cover with lock" on page 45.
â–¶
"Shutting down the server" on page 46.
â–¶
"Disconnecting the power cord" on page 47.
â–¶
"Getting access to the component" on page 48.
â–¶
"Locating the defective component" on page 44.
â–¶
Remove the corresponding riser module, see "Removing a riser module" on
page 63.
Removing the defective riser card
â–¶
Remove the expansion card, see "Removing an expansion card from a riser
module" on page 210 or the GPU card, see "Removing a GPU card" on
page 222.
Expansion cards and backup units
RX4770 M6 Upgrade and Maintenance Manual 225
