Replacing the iRMC microSD card
â–¶
Remove the defective iRMC microSD card, see "Removing the iRMC
microSD card" on page 348.
CAUTION
The iRMC microSD card contains customer information.
â–¶
After removing the iRMC microSD card, hand the card over to
the customer.
â–¶
If the customer requests disposal of the defective microSD card,
proceed as follows: Using a pair of side-cutting pliers, cut the
microSD card in half.
â–¶
Install the new iRMC microSD card, see "Installing the iRMC microSD card"
on page 346.
Concluding steps
â–¶
"Installing the OCP air duct" on page
73
.
â–¶
"Installing the top system board carrier" on page 76.
â–¶
"Installing the air duct 1 (top system board)" on page 71.
â–¶
"Installing the fan cage" on page 66.
â–¶
Install the riser modules, see "Installing a riser module" on page 63.
â–¶
"Reassembling" on page 53.
â–¶
"Connecting the power cord" on page 59.
â–¶
"Switching on the server" on page 60.
â–¶
If applicable, "Installing the front cover with lock" on page 61.
15.6 M.2 SSD
15.6.1 Slots and bolts for M.2 SSDs
The system board offers two M.2 slots with support for 80 mm and 110 mm
long M.2 SSDs by using different latch locations. With the M.2 SSD an internal
