Numbering of the fan modules
Figure 75: Numbering of the fan modules
1 Fan 1A/1B
2 Fan 2A/2B
3
Fan 3A/3B
4 Fan 4A/4B
8.3 Replacing a fan module
Customer Replaceable
Unit (CRU)
Hardware: 10 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 97
.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Getting access to the component" on page 48.
▶
"Locating the defective component" on page 44.
Fans
168 Upgrade and Maintenance Manual RX4770 M6
