Removing an SFP+ transceiver module
Figure 90: Removing the protective cap
â–¶
If present, remove the protective cap from the SFP+ transceiver module.
CAUTION
â–¶
Keep the protective cap for future use.
Expansion cards and backup units
184
Upgrade and Maintenance Manual
RX4770 M6
183
185
