ERR SUB A003 - Gantry Error Messages
102/002 HALT LIFT SPEED
ERROR
When a coding wheel defect is detected through the
complemented hardware (HW) lines, the IPMS stops
and forbids the motion and sends an error message.
See JC DIAG A1005 LIFT CONTROL FAILURE on
page 946 to fix the problem.
A1005
page 946
102/04 HALT LIFT LOWSPEED The signal coming from motor encoder contains four
phases. A, A complementary, B, B complementary.
The Lift node checks two things: complementarity +
sequence of phases.
Check the lift operation in low speed and then refer
to JC DIAG A1013 LIFT CONTROL FAILURE on
page 948 to fix the problem.
A1013
page 948
102/005 HALT UNCONTROLLED
LIFT MOTION
There has been a Correlation Error. In case signals
from absolute coder (potentiometer) and coding
wheel (motor encoder) are not correlated.
Refer to JC DIAG A1008 LIFT CONTROL FAILURE
on page 947 to fix the problem.
A1008
page 947
102/006 HALT LIFT FOOTSWITCH
DEFECT
SwitchDefect [i] (for i = 1 - 4) occurs when the two
signals from the button do not arrive at the same
time on the CPLD. [i] indicates the nature of the but-
ton and the side right or left. Double Footswitch con-
cerns 2 error signals and quadruple footswitches
concerns 4 error signals:
- Lift up
- Lift down
(- Compression up)
(- Compression down)
Refer to JC DIAG A1001 FOOTSWITCH IS
PRESSED on page 945 to fix the problem.
A1001
page 945
102/007 HALT LIFT FOOTSWITCH
DEFECT
102/008 HALT COMPRESSION
FOOTSWITCH
DEFECT
102/009 HALT COMPRESSION
FOOTSWITCH
DEFECT
102/010 HALT LIFT OVER UPPER
LIMIT
The IPMS detected that a motion has reached the
upper electrical stop limit. It stops and, forbids the
motion and sends an error message.
Refer to JC DIAG A1008 LIFT CONTROL FAILURE
on page 947 to fix the problem.
A1008
page 947
102/012 HALT LIFT OVER LOWER
LIMIT
The IPMS detected that a motion has reached the
lower electrical stop limit. It stops, and forbids the
motion and sends an error message.
Refer to JC DIAG A1008 LIFT CONTROL FAILURE
on page 947 to fix the problem.
A1008
page 947
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
