GE HEALTHCARERAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
4-8 Section 4-4 - Functional Checks
Section 4-4
Functional Checks
For a basic functional check of the system’s different modes, following pages will familiarize you with
image optimization for:
2D Mode (B Mode), see: Section 4-4-1 on page 4-9
Additional (optional) Operating Modes, see: Section 4-4-2 on page 4-12
-B-Flow
-XTD-View
- Coded Contrast Imaging
M Mode, see: Section 4-4-3 on page 4-14
- MCFM Mode
Spectral Doppler Modes, see: Section 4-4-4 on page 4-16
- PW - Pulsed Wave Doppler
- CW - Continuous Wave Doppler
Color Doppler Modes, see: Section 4-4-5 on page 4-17
- CFM - Color Flow Mode
- PD - Power Doppler
- TD - Tissue Doppler
- HD-Flow - Bi-Directional Angio
Volume Modes, see: Section 4-4-6 on page 4-19
- 3D Static
- 4D Real Time
- 4D Biopsy
- VCI - Volume Contrast Imaging (A-Plane, C-Plane and VCI Static)
-STIC
- T.U.I. (Tomographic Ultrasound Imaging)
- VOCAL II
NOTE: Some software may be considered standard depending upon system configuration.
If any Modes or Options are not part of the system configuration, the check can be omitted.
NOTE: Different menus are displayed depending on which Touch Panel Menu and which Mode is selected.
Some function keys only appear on the Touch Panel if they are available for the selected probe.
