Chapter 1 Introduction ProView 7000™ Platform Main Features and Configurations
© 2012 Harmonic Inc. 14 ProView 7000 v.2.6, Rev. E
Hardware options:
■ 1 x DVB-S/S2 or 4 x DVB-S/S2 inputs
■ Single or dual decoder
License options:
■ Multiple programs descrambling license (up to four TS descrambling, one channel
descrambling is license free)
■ DVB-S2 (requires DVB-S2 card)
■ 2 or 4 Transport streams routing
■ IP input
1.3.2 Multi-Format Decoder
The ProView 7000™/7100 can be configured as a multi-format video decoder. The
ProView 7000/7100 is for both Standard Definition (SD) and High Definition (HD) resolutions
for MPEG-2 and MPEG-4 AVC decoding.
Its wide choice of input options and video/audio interfaces ensures compatibility to all
reception and decoding application environments.
Basic configuration includes:
■ TS I/Os:
❑ 1 x DVB-S/S2
11
input
❑ 2 or 4 x ASI inputs
❑ 2 x GbE inputs
12
/outputs (virtual IP on the output stream)
❑ 2 x ASI outputs (4 x ASI outputs on ProView 7100™)
■ 2 or 4 x CI slots enabling single program descrambling
■ Decoder module video outputs (ability to configure up to two modules per unit):
❑ 2 x CV interfaces (2 outputs per video channel)
❑ 2 x SD/HD-SDI with embedded audio (2 outputs per video channel)
❑ 1 x analog video RGB-HD (15 pin connector)
❑ 1 x HD monitor interface (HDMI)
■ Decoder module audio outputs:
❑ 2 x balanced analog audio stereo output pairs (15 pin D-Sub connector)
❑ 2 x balanced AES/EBU digital audio outputs (15 pin D-Sub connector)
❑ 2 x unbalanced AES/EBU digital audio outputs (2 x BNC connector)
Hardware options:
■ 1x DVB-S or 4x DVB-S inputs
■ Genlock input (only with single decoder configuration)
■ Single or dual decoder
11. Requires a license with some hardware configurations, see B.6 Front End Card Features for details.
12. IP video input requires a license.
