Harmonic ProView 7100 - Appendix C Device Explorer Icons

© 2012 Harmonic Inc. 192 ProView 7000 v.2.6, Rev. E
Appendix C
Device Explorer Icons
Icon Description In Out
Enabled/
Connected
Disabled/
Disconnected
Physical Input/Output Icons
Port Holder
ASI Physical Port
DVB Physical Port
GbE Port
(active port)
GbE Socket
CAMs Holder
CAM Slot
(card inserted) (no card)
CAM Card
Decoder Module
Decoder Card
Decoder Output
Multiplexing In/Out Icons
Multiplexed Port
TS Port Route
Programs Holder
Program
Scrambled Program
Descrambled Program
