Chapter 3 Front Panel Overview Front Panel Display
© 2012 Harmonic Inc. 34 ProView 7000 v.2.6, Rev. E
3.2.1 Menu Pages
Menu pages display sub-menus and menu items.
Use the <up> and <down> arrow keys to move between the branches of the tree and press
<ENTER> to select and display the next lower level in the menu tree.
The front panel root menu of the ProView 7000™ is a simple menu screen.
To display the ProView 7000™ root menu:
❖ Press <ENTER> on the front panel default page.
See Appendix D, Front Panel Menu Tree for a diagram of the front panel menu tree.
3.2.2 Parameter Pages
The parameter pages displays the parameters of the element in the menu tree. They
comprise on the left side, a list of the parameter names and on the right side, parameter
values. Editable parameters have a pencil icon next to them. Parameters without the pencil
icon are read-only.
Use the <up> and <down> arrow keys to move between the parameters and press <ENTER>
to select an editable parameter to set-up. After pressing <ENTER>, an Edit Value or a Select
Value Screen is displayed to configure new values for the parameter.
Reception

SAT 1
SAT 2
SAT 3
SAT 4
Configuration
Universal Band Frequency
10.750000[GHz]
L Band Frequency
1.000000[GHz]
Symbol Rate
27500000[Baud]
Modulation Standard
DVB-S
