Chapter 6 Remote Management using EMS Removing a Device
© 2012 Harmonic Inc. 69 ProView 7000 v.2.6, Rev. E
6.10 Removing a Device
Removing, or Deleting a ProView 7000™ device from the EMS management, disconnects all
communication between the device and EMS and the device is no longer available via EMS.
To regain access to the device using EMS, add the device to EMS, see 6.5 Adding a Device for
details.
Removing a device from the EMS management can be performed on any ProView 7000™
device (i.e., listed in the Device box), regardless of its status; connected (full color icon),
disconnected (gray icon) or even a not responding device (red marked icon).
To remove a device:
1. Select the device which needs to be removed.
2. Click Remove on the EMS toolbar
—or—
select Action > Remove
—or—
press <Delete>.
A confirmation dialog displays.
3. Select OK.
The device is removed from the device list.
6.11 Displaying the Device Explorer
Prerequisites:
■ Device must be added to the Devices box
■ Device must be connected
To display the Device Explorer
1. Select the device in the Devices box of the EMS window.
2. Click Device Explorer in the EMS toolbar to display input and output stream trees.
6.12 EMS GUI Structure
The ProView 7000™ Element Management System (EMS) is an intuitive graphical user
interface (GUI) which enables you to manage ProView 7000™s over a LAN. The main EMS
components are:
■ Pull-down menus
■ Toolbar
■ The Devices box
■ The Device Explorer tabs
■ The Alarms tab
■ The Alarm History tab
See Figure 6–2 for EMS component names.
