Chapter 7
Device Configuring Using EMS
Topics:
■ Physical Input Ports and Slots
■ Multiplex Inputs
■ Multiplex & Decoding Outputs
■ Physical Outputs
■ Element Properties
■ Cross Connections
■ CAM Slot Management
■ EMS Connection Wizard
■ Low Delay Mode
■ Device Management
■ Device Properties
7.1 Physical Input Ports and Slots
The Physical Input box on the Device Explorer tab presents a hierarchical tree-structure of the
ProView 7000™ physical inputs, see Figure 6–2 for the box location.
Use the Device Explorer tabs to manage streams, physical ports, multiplexes and CAMM slots.
The ProView 7000™ has the following inputs:
■ ASI input ports.
■ DVB-S/S2
1
RF modulated inputs.
2
When the DVB-S/S2’s carrier and demodulator are locked, the icon LEDs are green, when
they are not locked the icon LEDs are red. See Figure 7–34.
■ GbE ports
3
.
■ CAM slots, responsible for the descrambling process.
To display the context menu:
❖ Right-click an element.
1. Requires a license with some hardware configurations, see B.6 Front End Card Features for details.
2. Not all hardware configurations support 4 demodulator ports, see B.6 Front End Card Features.
3. GbE in requires a license.
