Appendix B Connectors and Front End Card Options ProView 7000™ GPI Port Pin Configuration
© 2012 Harmonic Inc. 186 ProView 7000 v.2.6, Rev. E
B.3 ProView 7000™ GPI Port Pin Configuration
Figure B–6: D-Sub 9 Pinouts
Table B–3: D-Sub 9 Pinout Names
Pin No. Signal
1 N.U. 1
2NO 1
3
4COM 2
5NO 2
6COM 1
7
8
9 N.U. 2
12345
678 9
