4.4 Configuring the GbE Ports, Sockets and Routing Table
Use the GbE menu to configure the GbE ports, MPE PID, sockets and routing table.
To access the GbE menu:
❖ Navigate Root > GbE.
The GbE menu has the following sub-menus:
■ GbE Port 1/2 – Use these menus to configure the following:
❑ IP Configuration – Use this menu to configure the following:
• IP Address – The default is 127.127.0.X (X is the port number). Each port must have a
unique IP address.
• Subnet Mask – The default is 255.255.255.0.
• Gateway – Output only. The default is 127.127.0.1.
❑ MAC Address – Use this menu to view the MAC address for this port.
❑ Admin Status – Use this menu to view or set the Admin Status to one of the following:
• Up – Enable
• Down – Disable
If Admin Status is set to Up and no link is detected, a no link alarm is raised. The default
is Down.
❑ Auto Negotiation – Use this menu to view the Auto Negotiation status or set it to one of
the following:
•On
•Off
The default is On.
❑ PHY Speed – Use this menu to view the PHY speed. When Auto Negotiation is off you can
change PHY Speed to one of the following:
• 100
• 1000
The default is 1000.
❑ Duplex Mode – Only Full Duplex Mode is supported.
■ MPE
13
– Use the MPE menu to configure one MPE PID source for GbE out. There are three
service selection modes, Program, PID and Disabled.
The MPE menu comprises the following sub-menus:
❑ Mode:
• Program – Use this mode to configure an MPE PID by entering the program ID. The PID
is configured automatically.
• PID – Use this mode to configure an MPE PID by entering the PID.
• Disabled
❑ Input Port – Use this menu to select the multiplex input.
❑ Program Number – This menu only displays in Program mode.
13. Requires a license.
