B.1 Overview of Rear Panel Ports and Connectors
Figure B–1 and Figure B–2 illustrate typical ProView 7000™ rear panels and Table B–1 details
the ports and connectors provided on the panel. The single decoder card can be ordered with
or without the genlock feature and connector. The ProView 7000™ can be ordered with no
decoder card.
Figure B–1: ProView 7000™ Decoder Rear Panel with Single Decoder
Figure B–2: ProView 7000™ Decoder Rear Panel with Dual Decoder
DVB-S/S2
front-end module
Decoder module,
audio/video output interface
ASI in/out ports
Grounding
Jackscrew
AC power connector
and switch
Management
and service
MPEGoIP ports
Control and GPI
DVB-S/S2
front-end module
Dual decoder module,
audio/video output interface
ASI in/out ports
Grounding
Jackscrew
AC power connector
and switch
Management
and service
MPEGoIP ports
Control and GPI
