Chapter 4 Device Configuring Using the Front Panel Unit Menu
© 2012 Harmonic Inc. 55 ProView 7000 v.2.6, Rev. E
■ Auto Negotiation – activates the port auto negotiation capability.
Radio Button options: On and Off (Selection is not enabled. Always On).
■ PHY Speed – selects the physical layer speed.
Radio Button options: 100 and 1000 [Mbps] (Selection is not enabled. Set to 100 Mbps).
4.6.2 SW Version Menu
Use the SW Version menu to display the current version of the ProView 7000™ software.
4.6.3 HW Inventory Menu
Use the HW Inventory menu to display the part and version numbers of hardware modules
installed in the unit.
To access the ProView 7000™ Version Status menu:
❖ Navigate Root > Unit > HW Inventory.
The Hardware Inventory sub-menu contains the following items:
■ Platform – The Platform Properties sub-menu displays the following information:
❑ Part Number
❑ Serial number
■ Main Board – The Main Board Properties sub-menu displays the following information:
❑ Part Number
❑ Serial Number
❑ Main FPGA Version
❑ Auxiliary FPGA Version
■ Front End Card – The Front End Card properties sub-menu displays the following
information on the front end unit installed in the device:
❑ Part Number
❑ Revision Number
❑ Serial Number
❑ FPGA Version
❑ DVB-S2 Demodulator Version
❑ DVB-S Demodulator Version
■ Bottom Option Card – The Bottom Options card properties sub-menu displays the
following information:
❑ Part Number
❑ Revision Number
❑ Serial Number
❑ Decoder SW Version
NOTE: The Top Card and/or Bottom Card information is displayed only when the respective optional card
is installed.
