Appendix B Connectors and Front End Card Options Front End Card Features
© 2012 Harmonic Inc. 189 ProView 7000 v.2.6, Rev. E
B.6 Front End Card Features
Part Number Description Features
099-0526-0XX DVB-S/S2 Demodulator
■ 1 Port
■ DVB-S
■ Automatic DVB-S MODCOD selection
■ QPSK 1/2
■ QPSK 2/3
■ QPSK 3/4
■ QPSK 5/6
■ QPSK 7/8
■ Automatic spectral inversion mode
selection (DVB-S only)
■ DVB-S2
■ VCM (DVB-S2)
■ QPSK 1/4 (DVB-S2)
■ QPSK 1/3 (DVB-S2)
■ QPSK 2/5 (DVB-S2)
■ QPSK 3/5 (DVB-S2)
■ QPSK 4/5 (DVB-S2)
■ QPSK 8/9 (DVB-S2)
■ QPSK 9/10 (DVB-S2)
■ 8PSK 3/5 (DVB-S2)
■ 8PSK 2/3 (DVB-S2)
■ 8PSK 3/4 (DVB-S2)
■ 8PSK 5/6 (DVB-S2)
■ 8PSK 8/9 (DVB-S2)
■ 8PSK 9/10 (DVB-S2)
■ 16APSK 2/3 (DVB-S2)
1
■ 16APSK 3/4 (DVB-S2)
1
■ 16APSK 4/5 (DVB-S2)
1
■ 16APSK 5/6 (DVB-S2)
1
■ 16APSK 8/9 (DVB-S2)
1
■ 16APSK 9/10 (DVB-S2)
1
■ Frame size (DVB-S2 only):
64,800 or 16,200
■ Physical Layer Scrambling Seed (DVB-S2)
■ Acquisition mode
■ Frequency drift compensation from 5 MBd
and up
■ Spectral inversion
099-0536-1XX DVB-S Demodulator
■ 1 Port
■ DVB-S
■ Automatic MODCOD selection
■ QPSK 1/2
■ QPSK 2/3
■ QPSK 3/4
■ QPSK 5/6
■ QPSK 7/8
■ Frequency drift compensation
